Display Screen Size 55-inch (1209 mm)
Panel Type IPS / Direct-LED
Aspect Ratio 16:09
Effective Display Area 1209 x 680 mm
(W x H) (47.6 x 26.7)
Number of Pixels (H x V) 1920 x 1080 pixels
Brightness (Typ) 350 cd/m2
Contrast Ratio 1200:1
Response Time 9.0 ms (G to G)
Viewing Angle (Horizontal/Vertical) 178/178
(CR20)
Connection Terminal VIDEO IN 4-pole mini jack (M3) x 1
HDMI In HDMI TYPE-A connector x 2 * VIERA LINK is not supported.
DVI-D In/Audio In (L/R) DVI-D 24-pin x 1/Stereo Mini Jack (M3) x 1 (Shared with PC In)
PC In/Audio In (L/R) Mini D-sub 15-pin x 1/Stereo Mini Jack (M3) x 1 (Shared with DVI-D In)
USB USB connector (TYPE A) x 1, DC 5V/1A * USB 3.0 is not supported.
Control Serial D-sub 9-pin x 1, RS-232C Compatible
LAN RJ45 x 1 10 BASE-T/100BASE-TX, Compatible with PJLink
IR In/Out Mini Jack (M3) x 1/ x 1
Audio Audio Out Stereo Mini Jack (M3) x 1
Built-in Speaker 20 W [10 W + 10 W] (10% THD)
Electrical Power Requirements 110-127/220-240 V AC, 50/60 Hz
Power Consumption 170 W
On Mode Average Power Consumption*1 130 W
Power off Condition Approx. 0.3 W
Stand-by Condition Approx. 0.5 W
Mechanical Dimensions (W x H x D) 1239 x 712 x 62 mm (48.8 x 28.0 x 2.5)
Bezel Width 12.6 mm (0.5) (L/R/T), 14.5 mm (0.57) (B)
Weight Approx. 16.0 kg
(35.3 lbs.)
Pitch of Wall-hanging VESA Compliant 200 x 200 mm
