Screen Size (Diagonal) 42.0-inch (1,067 mm) 42-inch (1,067 mm) 42-inch (1,067 mm)
Aspect Ratio 16 : 9
Panel Type MVA / E-LED
Effective Display Area
(W x H) 930 x 523 mm (36.6″ x 20.5″)
Number of Pixels (H x V) 1,920 x 1,080 pixels
Brightness 350 cd/m2
Contrast Ratio 5,000:1
Response Time 9.5 ms (G to G)
Viewing Angle
(Horizontal/Vertical) 176° / 176°
Connection Terminal HDMI In HDMI Type A Connector x 1
DVI-D In/Audio In (L/R) DVI-D 24-pin x 1 / M3 Jack x 1 (Shared with PC In)
PC In/Audio In (L/R) Mini D-Sub 15-pin x 1 / M3 Jack x 1 (Shared with DVI-D In)
CONTROL Serial D-Sub 9-pin x 1, RS-232C Compatible
LAN RJ45 10BASE-T/100BASE-TX, Compatible with PJLink™
AUDIO Line Out (VAO) M3 Jack x 1
Built-in Speakers 10 W [5 W + 5 W]
Electrical Power Requirements AC 110-127 V
50/60 Hz
AC 220-240 V
50/60 Hz AC 220-240 V
50/60 Hz
Power Consumption 65 W 65 W 65 W
Power off Condition Approx. 0.5 W Approx. 0.5 W Approx. 0.5 W
Stand-by Condition Approx. 0.5 W Approx. 0.5 W Approx. 0.5 W
Mechanical Dimensions (W x H x D) 957 x 564 x 49 mm (37.7″ x 22.2″ x 2.0″)
Bezel Width 9.0 mm (0.4″) (L/R/T), 10 mm (0.4″) (B)
Weight Approx. 13.5 kg (29.8 lbs.)
Operation Environment Temperature 0 °C to 40 °C (32 °F to 104°F)
